E2B-S08KN04-WP-C1 2M Omron Proximity Sensor

Voltage	+/-1% max. of sensing distance in 24 VDC +/-15%
Usage/Application	Object Detection
Color	Silver
Sensing Distance	4 mm +- 10%
Size/Dimension	12 x 12 x 1 mm
Frequency	1,000 Hz (Response)
Power	10 to 30 VDC. (including 10% ripple (p-p))
Weight	Short body Approx. 65g
Output Type	-B models PNP open collector -C models NPN open collector
Insulation Resistance	50 M ohm min. (at 500 VDC) between current-carrying parts and case
Indication Type	Operation indicator (Yellow LED)
Dielectric Strength	1,000 VAC at 50/60 Hz for 1 min between current-carrying parts and case
Shock Resistance	500 m/s2
Vibration Resistance	10 to 55 Hz
Humidity	Operation and Storage 35 to 95%
Connectivity	Pre-wired models (standard is 4 mm dia. PVC cable with length = 2 m, 5 m). Connector models (M8-3pi
Load Current	200 mA max. (30 VDC max.)
Supply Current	10 mA max.
Operating Temp.	Operation and storage -25 to 70 DegreeC (with no icing or condensation)
Ip Degree Of Protection	Power source circuit reverse polarity protection
Country of Origin	Made in India
